Grinding Machine / Wheels
Model SFI-01 designed for accurate spring end grinding and consistent surface finish.
Precision grinding for spring ends
SLM series CNC spring end grinding machine is mainly used for grinding the double sides of compression springs (including cylindrical springs, conical springs, and double conical springs). The machine uses two upright grinding wheels with adjustable feeding speed and height control, allowing the spring to reach a preset height and achieve maximum grinding capacity according to pressure settings. It includes self-compensation, self-reset, and alarm functions. Human-machine interaction enables programming via the screen for easy operation and higher productivity.
Specification
Reference specification image extracted from the catalog.
| Parameter | SLM180-6B | SLM180-6B-S | SLM250-9B | SLM250-9B-S | SLM600-9B | SLM250-12B | SLM400-12B |
|---|---|---|---|---|---|---|---|
| Specification of Grinding Wheel | Phi 400 x 55 | Phi 400 x 55 x Phi 203 | Phi 450 x 65 | Phi 450 x 65 x Phi 50 | Phi 450 x 65 | Phi 600 x 100 x Phi 170 | Phi 600 x 100 x Phi 170 |
| Diameter of Feeding Plate (mm) | Phi 580 | Phi 420 | Phi 740 | Phi 580 | Phi 740 | Phi 740 | Phi 740 |
| Wire Diameter (mm) | Phi 0.8 - Phi 6 | Phi 0.8 - Phi 6 | Phi 1 - Phi 9 | Phi 1 - Phi 9 | Phi 1 - Phi 9 | Phi 3 - Phi 12 | Phi 3 - Phi 12 |
| Spring Outside Diameter (mm) | Phi 8 - Phi 80 | Phi 8 - Phi 80 | Phi 10 - Phi 100 | Phi 10 - Phi 100 | Phi 10 - Phi 100 | Phi 20 - Phi 130 | Phi 20 - Phi 130 |
| Spring Height (mm) | 10 - 180 | 10 - 180 | 20 - 250 | 20 - 250 | 300 - 600 | 20 - 250 | 150 - 400 |
| Machine Dimension (mm) | 2050 x 1660 x 2120 | 2050 x 2060 x 2120 | 2215 x 1900 x 2400 | 2215 x 2265 x 2400 | 2215 x 2000 x 2850 | 2600 x 2100 x 2800 | 2600 x 2100 x 3060 |
| Upper Grinding Wheel Motor (kw) | 4 | 4 | 5.5 | 5.5 | 7.5 | 12.5 | 12.5 |
| Lower Grinding Wheel Motor (kw) | 4 | 4 | 5.5 | 5.5 | 7.5 | 12.5 | 12.5 |
| Feeding Plate Motor (kw) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 3 | 3 |
| Switch Feeding Plate Motor (kw) | / | 1.5 | / | 1.5 | / | / | / |
| Elevating Motor of Upper Grinding Wheel (kw) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 2.2 | 2.2 |
| Elevating Motor of Lower Grinding Wheel (kw) | 0.18 | 0.18 | 0.18 | 0.18 | 0.18 | 0.37 | 0.37 |
| Air Blower (kw) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 x 2 | 1.5 x 2 | 1.5 x 2 |
| Compensated Motor of Upper Grinding Wheel (kw) | 0.14 | 0.14 | 0.14 | 0.14 | 0.14 | 0.14 | 0.14 |
| Total Power (kw) | 12.82 | 14.32 | 15.82 | 17.32 | 21.32 | 33.71 | 33.71 |
| Rotation Rate of the Feeding Plate (r/min) | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable |
| Rotation Rate of the Grinding Head (r/min) | 1450 | 1450 | 1450 | 1450 | 1450 | 965 | 965 |
| Upper Grinding Head Displacement Distance (mm) | 180 | 180 | 250 | 250 | 250 | 250 | 400 |
| Lower Grinding Head Displacement Distance (mm) | 40 | 40 | 50 | 50 | 50 | 70 | 70 |
| Verticality (Ho) | <= 0.025 | <= 0.025 | <= 0.025 | <= 0.025 | <= 0.025 | <= 0.025 | <= 0.025 |
| Roughness (Ra) | <= 12.5 | <= 12.5 | <= 12.5 | <= 12.5 | <= 12.5 | <= 12.5 | <= 12.5 |
| Power Source | 3-phase 380V AC 50HZ | 3-phase 380V AC 50HZ | 3-phase 380V AC 50HZ | 3-phase 380V AC 50HZ | 3-phase 380V AC 50HZ | 3-phase 380V AC 50HZ | 3-phase 380V AC 50HZ |
| Net Weight of the Machine (kg) | 2200 | 2500 | 2800 | 3500 | 4500 | 5500 | 6000 |
