Special Purpose Machine
Hook Making Series
Hydraulic control machines for 2D and 3D hook shapes with automatic bending and welding.
Hydraulic control hook forming
- Produces 2D and 3D hook shapes, including J hooks and hanging hooks.
- Supports custom hook profiles based on customer requirements.
- Designed for stainless steel buckle bending and automatic welding.
- Stable output suited for supermarket and display applications.
Technical Parameter
Specifications extracted from the provided image.
| Model | SFI-RH12 | SFI-JH12 | SFI-JH10W | SFI-JH12W | SFI-DB-6W |
|---|---|---|---|---|---|
| Wire Size | 6.0-12.0 mm | 5.0-12.0 mm | 5.0-10.0 mm | 6.0-12.0 mm | 2.0-6.0 mm |
| Feeding Length | 0-300 mm | 0-300 mm | 0-300 mm | 0-300 mm | 0-300 mm |
| Production Capacity / Minute | 15-18 pcs | 12-15 pcs | 10-12 pcs | 8-10 pcs | 16 pcs |
| Motor Power | 5.5 kw | 5.5 kw | 5.5 kw | 7.5 kw | 5.5 kw |
| Welding | No | No | Yes | Yes | Yes |
| Dimensions (L x W x H) cm | 195 x 125 x 186 | 195 x 135 x 186 | 195 x 130 x 186 | 195 x 130 x 186 | 195 x 130 x 186 |
| Weight | 1300 kg | 1200 kg | 1300 kg | 1400 kg | 1300 kg |
